Dump semi Trailer
Rear/Tipping dump trailer
Overall Dimension	1300026002800mm or Customized
Curb Weight	10,000 kg
Loading Capacity	100,000 kg
Main Beam Spec.	Carbon Steel, Upper 18mm, bottom 20mm, middle plate 8+8 mm
Side Frame	Channel Steel
Cross Brace	Channel Steel/Bending Steel
Bucket	Carbon Steel, Bottom 9mm, Side 6mm
Suspension	3 Mechanical Suspensions + 3 Air Suspensions
Leaf Spring	13-layers leaf spring 120mm13mm10pcs
Axle Spec.	16T * 6pcs
King Pin	2"(50mm)or3.5"(90mm)
Tire	12.00R20
Brake Chamber	12sets
Landing Gear	28T*2
Accessories	1 Standard Tool Box
Electric System	24V, One Set 6-core Standard Cable
Light	Tail lamp with turn signal,brake light & reflector,side lamp etc
Painting	Sand blasting, prime coating, surface painting,color optional, wax polishing
Packing	Bulk Cargo Vessel, Ro-ro Shipment or Optional

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension 1

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension 2

Frequently Asked Questions

Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

Primary method: Shipping by container or ro-ro/bulk vessel
For neighboring countries: Road or rail transport
For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX

Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.

Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.

Email: juyuan@aotongtrailer.com

Phone: +86 139 6962 7783

With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.

Las etiquetas:

dump semi trailer,

DETALLES DE LOS PRODUCTOS

Productos

Semi-remolque con lecho bajo

Semiremolque de contenedor

Remolque de la pared lateral semi

Semiremolque de transporte de vehículos

Semiremolque de descarga y desviación

Semi-remolque lateral de Van&Curtain

Cerca Semi Trailer

Semiremolque para el transporte de animales

del petrolero remolque semi

Remolque agrícola y otro remolque completo

El camión Howo

cabeza del tractor

Trailer especial

Partes de repuesto de remolque

Nuevos vehículos de la energía

Vehículos especiales

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension

Cuota De Producción:	1 unidad
Embalaje Estándar:	Estándar de exportación
Período De Entrega:	25 días
Método De Pago:	T/T

Información detallada

Descripción del producto

Información detallada

Lugar de origen

Porcelana

Nombre de la marca

AOTONG

Certificación

ISO,CCC

Suspensión:

Suspensión mecánica o de aire

Especificaciones de neumáticos:

12R22.5

Haz principal:

Servicio pesado I Beam.

Alfiler:

2 ''/3.5 '' Tipo de perno

Sistema de frenado:

Cámara de aire doble, válvula de freno, 45 láscinos de aire; ABS opcional

Eléctrico:

Luz LED, 7 maneras, 24 V

Cuadro:

Platagia y óxido limpio, 1 capa de pintura primaria, 2 capa de pintura de acabado

Cantidad de orden mínima:

1 unidad

Detalles de empaquetado:

Estándar de exportación

Tiempo de entrega:

25 días

Condiciones de pago:

T/T

Resaltar

heavy duty hydraulic dump trailer

air suspension rollover trailer

120T tipping semi trailer
